Description
The NS-X122 removes the green husk from macadamia nuts at approximately 500 kg/h, more than three times the output of the entry-level NS-X121, using a 4 kW three-phase motor. It keeps the same integrated pit-separation design so husk and nut are separated in one pass, and it is sized for farms and workshops that already run a drying or cracking line downstream.
Technical specifications of the NS-X122
| Model | NS-X122 |
|---|---|
| Capacity | ~500 kg/h |
| Dimensions (L x W x H) | 820 x 580 x 1,000 mm |
| Weight | ~130 kg |
| Power supply | 4 kW, 380 V |
| Body material | Carbon steel |
| Packing volume | 0.80 CBM |
| Packed weight | ~180 kg |
What the NS-X122 handles
- Freshly harvested macadamia nuts with green husk attached
- Around 4 tonnes of nuts per 8-hour shift
- Feeding a downstream dryer, cracker or shelling line
Key features
- ~500 kg/h throughput, roughly 3x the NS-X121
- 4 kW three-phase 380 V drive
- Integrated pit separation in a single pass
- Compact 820 x 580 x 1,000 mm body weighing about 130 kg
- Cost-effective choice for small and medium processing plants
Frequently asked questions about the NS-X122
What is the throughput of the NS-X122 husker?
The NS-X122 is rated at approximately 500 kg/h of fresh macadamia, or about 4 tonnes over an eight-hour shift. That makes it roughly three times faster than the smaller NS-X121 while using a modest 4 kW motor.
Does the NS-X122 need three-phase power?
Yes. The NS-X122 uses a 4 kW three-phase motor on 380 V, so it needs a three-phase supply. If you only have single-phase power, the NS-X121 and NS-X123 accept 220 V.
How is the NS-X122 different from the NS-X123?
Both machines separate husk from nut in one pass. The NS-X122 runs at about 500 kg/h with a 4 kW motor in a low, wide body, while the NS-X123 runs at 300 kg/h with a 3 kW motor in a taller 1,400 mm frame that gives more separation travel for thick or uneven husk.
Can the NS-X122 be used with a complete processing line?
Yes. The NS-X122 is normally placed first in a line, ahead of a dryer or cracker, and can run continuously during a shift. Tell us the machines downstream when you ask for a quote and we will confirm belt heights and capacities match.
How do I get a price and lead time?
Email nanshengtechnology@gmail.com or message +86 133 7302 3075 on WhatsApp. Minimum order is one unit, and we quote FOB with the port and packing details included.
Request a quote or ask a question
Tell us what you need and our sales team will come back with price, packing size, shipping options and lead time, usually within one business day.
- Email: nanshengtechnology@gmail.com
- Phone / WhatsApp: +86 133 7302 3075
To get an accurate quotation, please tell us:
- The material you process (macadamia, cashew, pine nut, coffee cherry, other nuts)
- Your target output per hour or per day
- Your power supply: 220 V single phase or 380 V three phase
- Your destination port or country
Minimum order quantity is one unit. OEM branding and customisation are available on request, and specifications are confirmed in writing before production. Dongguan Nansheng Technology Co., Ltd., Dongguan, Guangdong, China.
